Round Double Wire Lock Pin With Clip

Linkgo Farm Round double wire lock pin with clip. Made from carbon steel with a zinc finish for durability and brilliance, Single or double strand made of low carbon steel, zinc plated, Inch or Metric pin diameter, Available in stainless steel and customization. Wire lock pins are like having pin and cotter in one secure assembly!

● Round Shaft Locking Pin 1/4 x 2 Inch
● Round Shaft Locking Pin 5/16 x 1-3/4 Inch
● Round Shaft Locking Pin 3/8 x 2-1/4 Inch

Round Double Wire Lock Pin With Clip Video

Round Wire Lock Pin Specification

         Round Loop Wire Lock Pin                Linkgo Farm Quick Release Pin Round Tap Wire Lock Pin

PART NO.

Nominal
(D)
Effective
Length
(EL)
Shank
Length
(SL)
Handle
Style
WEIGHT
INCH MM INCH INCH R/S KG/PCS
WL250-175R 1/4 6 1-3/4 2 Round 0.033
WL250-175S 1-3/4 2 Square 0.033
WL250-225R 2-1/4 2-1/2 Round 0.040
WL250-225S 2-1/4 2-1/2 Square 0.040
WL250-250R 2-1/2 2-3/4 Round 0.042
WL250-250S 2-1/2 2-3/4 Square 0.042
WL312-137R 5/16 8 1-3/8 1-5/8 Round 0.038
WL312-137S 1-3/8 1-5/8 Square 0.038
WL312-175R 1-3/4 2 Round 0.045
WL312-175S 1-3/4 2 Square 0.045
WL312-225R 2-1/4 2-1/2 Round 0.049
WL312-225S 2-1/4 2-1/2 Square 0.049
WL312-250R 2-1/2 2-3/4 Round 0.054
WL312-250S 2-1/2 2-3/4 Square 0.054
WL375-137R 3/8 10 1-3/8 1-5/8 Round 0.042
WL375-137S 1-3/8 1-5/8 Square 0.042
WL375-150R 1-1/2 1-3/4 Round 0.043
WL375-150S 1-1/2 1-3/4 Square 0.043
WL375-175R 1-3/4 2 Round 0.051
WL375-175S 1-3/4 2 Square 0.051
WL375-225R 2-1/4 2-1/2 Round 0.058
WL375-225S 2-1/4 2-1/2 Square 0.058
WL375-250R 2-1/2 2-3/4 Round 0.064
WL375-250S 2-1/2 2-3/4 Square 0.064



Key Features of Round Shaft Locking Pin

                                                        Round Wire Lock Pin Shaft Locking Pin

To better understand Round Shaft Locking Pin, let's look at some of the key features that make Round Shaft Locking Pin such a popular choice:



1. Round Shaft Locking Pin Mechanism: The defining feature of these pins is the loop at one end, which acts as a spring-loaded locking mechanism. This loop snaps into place once the pin is inserted, providing a secure connection that prevents it from sliding out.

2. Round Shaft Locking Pin Quick Release Design: The loop allows for quick and tool-free release, making it easy to disengage the pin when necessary, without compromising on the security of the fastening.

3. Variety of Sizes: Round loop wire lock pins come in a wide range of diameters and lengths to accommodate different applications. This versatility allows users to find the perfect fit for their equipment.

4. High-Strength Materials: Made from durable materials such as carbon steel or stainless steel, these pins are built to withstand heavy loads and harsh environments. Many pins also feature protective coatings such as zinc plating for enhanced corrosion resistance.

Applications of Round Shaft Locking Pin For

1. Round Shaft Locking Pin For Agricultural Machinery

In farming and agricultural operations, round loop wire lock pins are frequently used to secure attachments such as plows, harrows, cultivators, and other farm implements to tractors. Their quick release design allows for easy attachment changes, improving efficiency on the field.

2.Round Shaft Locking Pin For Trailer Couplings and Hitches

Linkgo Round Wire Lock Pin Application

In the transportation industry, round loop wire lock pins are commonly used to secure trailer hitches, couplings, and other towing equipment. They provide a safe and reliable connection between trailers and towing vehicles, ensuring stability even on rough roads.

3.Round Shaft Locking Pin For Construction Equipment

Heavy-duty construction machinery often features movable parts or attachments that require secure fastening. Round loop wire lock pins are ideal for locking components such as buckets on excavators, stabilizing arms, or other accessories on bulldozers and cranes.

4. Round Shaft Locking Pin For Automotive Industry

In automotive applications, round loop wire lock pins are used for various fastening tasks, including securing tow bars, racks, and removable components. Their robust design and easy handling make them perfect for frequent usage.

5. Round Shaft Locking Pin For Sports Equipment and Recreation

Round loop wire lock pins are often used in the assembly of sports equipment, such as stabilizing sports nets, securing bike racks, or assembling portable bleachers. Their ease of use makes them ideal for leisure activities that require fast assembly and disassembly.

6. Round Shaft Locking Pin For Marine and Boating

For marine applications, stainless steel versions of round loop wire lock pins are commonly used to secure components exposed to water, salt, and harsh marine environments. They are resistant to corrosion and are perfect for boat trailers, dock assemblies, and rigging.

Customization Service For Round Shaft Locking Pin

Customization Service for Round Shaft Locking Pins allows clients to tailor pins to their specific application needs. This service typically includes modifications to the pin’s dimensions, materials, and locking mechanisms to meet industry standards and unique usage requirements. Customization options may include:



1.  Round Shaft Locking Pin Diameter & Length Adjustments:

Custom sizing to precisely fit the client's equipment, ensuring a secure fit in a variety of applications.



2.  Round Shaft Locking Pin Material Choices:

Options for materials like stainless steel, carbon steel, or specialty alloys for increased strength, corrosion resistance, or environmental suitability.



3.  Round Shaft Locking Pin Finish & Coating:

Custom finishes such as zinc plating, powder coating, or anodizing to enhance durability, corrosion resistance, and aesthetic appeal.



4.  Round Shaft Locking Pin Locking Mechanism Types:

Custom locking mechanisms, such as detent balls, spring-loaded clips, or wire retainers, to meet specific security and operational needs.



5.  Round Shaft Locking Pin Tolerances & Strength:

Tailoring for specific tolerances and load capacities to accommodate heavy-duty or precision applications, ensuring performance in challenging environments.



6. Special Features:

Options like laser engraving for branding or identification, knurled grips for better handling, or colored coatings for easy recognition.



This customization service is ideal for industries like agriculture, construction, manufacturing, and transportation, where unique or specialized machinery requires precisely fitted, durable components. Each custom order is designed to ensure safety, ease of use, and longevity tailored to the client's equipment and operational conditions.
